MINIWIN is a laboratory package single inside-out flow dyeing machine that is specially used for dyeing one package. With unique wave dyeing technology, the dyeing effectiveness is consistent with the large production package dyeing machine.

PRODUCT

MINIWIN

MINIWIN

(Dyeing machine)

This laboratory package single flow dyeing machine has a simple configuration making it an excellent tool in laboratory for every dyeing plant. The unique wave dyeing technology ensures uniform dyeing across the package. It requires only a sufficient water level at the kier bottom to maintain steady pump operation and not necessary to have all packages immersed with liquor, hence achieving a lower liquor ratio.
Manufactured by: Fong's National Engineering Co., Ltd., Hong Kong

  • FEATURES
  • BENEFITS
  • RESOURCES
  • GET A QUOTE
More
      Technical Details
  • Cooling gradient: 130-80°C approx 5°C/min (cooling water at 3 bar, 25°C)
  • Heating gradient: 25-100°C approx 4.7°C/min
  • Design pressure: 4.4 bar
  • Design temperature: 140°C
  • 100-130°C approx 3.6°C/min (heated by electricity)
  •   Key Features
  • Compact piping layout
  • Comes with a dosing tank
  • Directly heated by electrical heater instead of external steam heating coil
  • With unique fuzzy logic temperature control technology, temperature can be confined to ±0.3°C
  • Made of 316Ti/1.4571 stainless steel
  • Low liquor ratio ensures high reproducibility
  • Small size around 1 m in dimension
  • Convenient to be operated on workbench
  • Suitable for laboratory usage
