KARL MAYER's Nov-O-Matic (NOM) automatic sectional warping machine is an economic alternative for the production of high quality short warp.

PRODUCT

Nov-O-Matic NOM

Nov-O-Matic NOM

(Automatic sectional warper for short and long warp length)

An automatic leasing function (freely selectable) with up to 7 size separation lease guarantees a wide range of applications. A laser-controlled band build-up provides identical band circumferences and section-trolley feed without correction stops. The highly effective end break detector ensure optimal processing with superior efficiency on the weaving machine.
Manufactured by:  KARL MAYER, Germany

  • FEATURES
  • BENEFITS
  • RESOURCES
  • GET A QUOTE
More
      Technical Details
  • Application range: shirting, worsted, silk, bottom weights, home textiles, and apparels
  •   Key Features
  • KAMCOS SYSTEM - operator interface IPC/touch screen 12.1", ethernet interface for networking and connection for the relevant data acquisition and tele-service
  • Compact beaming device for easier operation
  • Computer and laser-controlled band-build-up - real time measurement from the first to the last section with central yarn tension control for perfect weaving beams
  • Shed opener and control - for secure and fast leasing
  • Smaller warping drum 600 mm dia for faster positioning/breaking
  • Automatic leasing and section-changeover
  • Genuine leasing cord automatically inserted, reduced manual handling before beaming operation
  • Working width range available: 2200 mm and 3600 mm
  • Maximum warping speed: 1000 m/min
  • Maximum beaming speed: 200 m/min
  • Reduced section change and leasing time compared to conventional sectional warping machines
  • Robotic operation in section change and leasing ensures high productivity
  • Guarantees efficient production combined with the highest warp quality
  • High quality warps as a result of laser-monitored circumferential control in association with layer thickness control
