Long tube ' L' shaped soft flow dyeing machine with facility for running fabrics in either 1 or 2 ropes per tube.

PRODUCT

ECO-8

ECO-8

(Multi rope soft dyeing machine)

The ECO-8 is a long L shape machine that handles the fabric very gently. Depending on the design of the fabric conveyance system, the three series of models are able to run fabrics in one, two or three ropes per tube. A wide range of machine models are available to process very heavy and very light fabrics, such as piles and single jersey respectively. Also by incorporating the advanced automatic control devices, Multi-function Stock Tank (MST) and control software, the ECO-8-SR with super functions allows the shortest dyeing time to only 298 minutes. The total water consumption is as low as 38 l/kg. The highly efficient and cost effective ECO-8 provides the competitive edge to meet ever-changing market demands. With the use of advanced polymeric material, the ECO-8 maintains among its types the extra low liquid ratio of 1:6 at a maximum tube capacity up to 550 kg.
Manufactured by: The Fong's Industries Group, Hong Kong

  • FEATURES
  • BENEFITS
  • RESOURCES
  • GET A QUOTE
More
      Technical Details
  • Liquor ratio: 1:6
  • Maximum speed: from 250-400 m/min depending on machine type
  • Design temperature: 140°C+
  • Design pressure: 3.5 bar
  • Heating rate: 25°C-100°C, average 5°C/min; 100°C-130°C average 2.5°C/min (dry saturated steam pressure at 7 bar)
  • Cooling rate: 130°C-100°C average 3°C/min 100°C-85°C, average 2°C/min (cooling water at 3 bar, 25°C)
  •   Key Features
  • Machine body and major parts wetted by dyeing liquid are made of 316Ti/316L/1.4571/1.4404/2304 corrosion resistant stainless steel
  • Highly efficient stainless steel centrifugal pump
  • Lifter reel driven by frequency inverter controlled gear reduction motor
  • ATS Nozzle
  • Automatic fabric upper tangling release device
  • Pneumatic control valves for heating and cooling, with fuzzy logic temperature control function
  • Pneumatic valves for fill, drain and overflow rinse function
  • Internal spray cleaning device
  • Highly efficient tubular heat exchanger
  • Pressurising and depressurising system for main kier level indicator with level sensor
  • Service tank with feed pump, valves, stirring function and dosing control with high precision flow control device take off roller
  • Multi-core control cable
  • Service platform with FRC plank grating
  • Main control cabinet with FC28 program controller
  • Multi-Saving Rinsing System (MSR)
  • Dyeing time as short as 316 minutes
  • Less water and energy consumption
  • Less effluent
  • Minimal human intervention
  • Constant liquor ratio
  • Accurate dosing control
  • Advanced drop bath technique without stopping the machine
