Power-Heat-Set GmbH has been supplying the carpet industry with machines and components for carpet yarn treatment for over 40 years. The machines are manufactured in Germany by highly-qualified technicians and offer proven reliability, flexibility, and productivity in continuous heatsetting.

PRODUCT

Carpet yarn heatsetting machine

Carpet yarn heatsetting machine

Power-Heat-Set’s machine portfolio currently offers two different machine types, namely GVA and HiPerSet and both are available in three different sizes. The machines can heatset both natural and synthetic fibres using overheated steam under atmospheric pressure.
The design of these machines makes them very energy efficient. Low energy costs make the operation of the machines very economical without affecting the high processability and still achieving a very high carpet quality yarn.

GVA
The GVA offers the best flexibility and high performance for heatsetting carpet yarn with up to 96 ends. Due to the GVA’s 6 channel configuration heatsetting of small lots on different belts, it is even possible to run different colours of the same yarn or straight set and frieze at the same time.

HiPerSet
The HiPerSet is Power-Heat-Set’s single belt solution for heatsetting the yarn with overheated steam. Depending on the model up to 84 ends can be processed at the same time. Due to its design, the HiPerSet offers easy maintenance and operation.

Manufactured by: Power-Heat-Set GmbH, Germany

  • FEATURES
  • BENEFITS
  • RESOURCES
  • GET A QUOTE
More
      GVA
  • Production up to 14 tons per day (depending on the model)
  • Computer-controlled dew point regulation (steam control)
  • Range of temperature for heatsetting between 110-200°C
  • Temperature monitoring on each heatsetting channel
  • Energy saving design
  • Quick yarn break removal
  • Optimal yarn cooling
  •   HiPerSet
  • Production up to 12 tons per day (depending on the model)
  • Computer-controlled dew point regulation (steam control)
  • Range of temperature for heatsetting between 110-200°C
  • Temperature monitoring on each heatsetting channel
  • Energy saving design
  • Quick yarn break removal
  • Optimal yarn cooling
  • Vacuum system for easy and defined yarn take-off
      GVA
  • Maximum flexibility
  • Possibility to process different specifications (frieze, colour, etc.) at a time
  • High efficiency factor when yarn breaks occur (5/6th of machine capacity keeps on running)
  • More bulk and coverage or with defined pin point effect
  • Better dyeing affinity due to high temperature heatsetting
  • Improved colour fastness for printed carpets
  • Yarn is highly resistant to stains and soiling
  • Heat setting of 6 different yarns at a time
  •   HiPerSet
  • More bulk and coverage or with defined pin point effect
  • Better dyeing affinity due to high temperature heatsetting
  • Improved colour fastness for printed carpets
  • Yarn is highly resistant to stains and soiling
