ViewAXIS Tera

ViewAXIS Tera

(Full repeat web viewing system)

The ViewAXIS Tera is a full print repeat web viewing system for superior process monitoring. It captures sharp, high resolution, 'near print' quality images at full production speeds using fast and high resolution line scan cameras. This allows the operator to monitor the entire repeat precisely and efficiently. The output is displayed on a 55" 4K LED screen with true colour display, enabling the operator to locate the defects and identify errors quickly. The ViewAXIS Tera can show a stationary image of the entire width of the print web. By looking at this image, the operator can easily spot errors and defects and take corrective action, thus reducing wastage of print material. Magnification and other image control features assist the operator to inspect the repeat minutely, thus helping improve print quality.
Manufactured by: A.T.E. Enterprises Private Limited, India


Conventionally during production, an operator would constantly check the print quality of the substrate with the naked eye. However, at high web speeds, this is impossible. Conventional web videos allow the operator to view a stationary image of only a section of the printed substrate. With constantly increasing demands for superior print quality and reduced material wastage, converters need a system to monitor the full print repeat. The ViewAXIS Tera ensures superior print quality, reduced material rejection, and improved productivity.

      Technical Details
  • Monitor: 55" display, 22" touch screen monitor for operation
  • Camera resolution: >170 DPI
  • Viewing area: dynamic
  • Camera unit: line scan camera
  • Flash unit: LED Brightfield
  • Area magnification: 4x digital zoom
  • Print speed: 500 m/min
  • Power supply: 230V AC 50 Hz
  •   Key Features
  • Instant error identification
  • Magnification and brightness control function for better image viewing
  • Real time split screen function for traffic lights/cross marks comparison on both edges
  • Image rotation option and horizontal/vertical flip options
  • Bright white light LED strobe with variable intensity
  • 1:1 image viewing
  • Fit to screen viewing
  • Repeat scan mode and selection of critical areas
  • Online diagnostics and support
  • System can be used for any type of roll to roll printing applications
  • Supports all materials like BOPP, Polyester, aluminium foil, LDPE
  • Interactive user interface
  • Precise and efficient web monitoring
  • Full print repeat monitoring
  • Better image control
  • Low power resolution
  • Scanning of critical positions
  • Suitable for different types of material
  • Easy to operate
  • Reduces waste, start-up time, and improves productivity
