Valstat® Fan Based Static Eliminator

Valstat® Fan Based Static Eliminator

(Eliminating static from a stationary or moving object.)

The Valstat® BS 11 provides a flow of ionised air which can ideally travel over a distance of 500 mm, thereby eliminating static from a stationary or moving object. Valstat® PS 74 U power sources are designed to provide high voltage AC supply to the Valstat® BS 11 static eliminator. They give stable high voltage output even under severe conditions.
Manufactured by: A.T.E. Enterprises Private Limited, India

      Key Features
  • Valstat® make static eliminator built into the system
  • Powder coated, mild steel construction
  • Weight 6 kg/900 mm effective length; 166 mm W × 105 mm D
  • Air volume of 145 cubic meters per hour per 150 mm Effective Length (EL)
  • Stable HV output, with in-built current limit
  • Shock-less
  • From external Valstat® PS 70 R power source through 2 m HV cable
  • Compact, dust-proof & rugged construction
  • Power consumption of 20 W per 150 mm EL
  • Power supply of 230 V, 50/60 Hz, single phase input to fans through 5 m PVC cable
  • 2 m input cable; built-in fuse and power switch
  • Working distance up to 500 mm, under ideal conditions
  • Mild steel fabricated, powder coated enclosure
  • Extended working distance of up to 500 mm
  • Provides stable high voltage output even under severe operating conditions
  • Can eliminate static from 2D and 3D objects
  • Easy installation and start-up
  • Very low power consumption - 50 W
