AlygnAXIS Automatic Register Control System

AlygnAXIS Automatic Register Control System

AlygnAXIS is designed to increase productivity, maximise operational flexibility, and reduce waste. AlygnAXIS has one of the fastest correction signals among register control systems. This, coupled with reliable hardware and software ensures accurate measurement, excellent control, and consistent performance, which ensures consistent print quality and reduced waste. It is packed with novel features and a user-friendly GUI.
Manufactured by: A.T.E. Enterprises Private Limited, India


Print quality, productivity, reduction of waste and cost competitiveness are the main challenges faced by the print and packaging industry. Responding to these challenges, A.T.E. has developed AlygnAXIS - an upgraded version of its highly successful predecessor, Alygn. With over 35 years of domain expertise, 200+ domestic and international installations through OEMs and end users in India, Europe, China and Middle East, AlygnAXIS, has proved itself to be robust and dependable.

      Technical details:
  • Min. speed: 5 m/min
  • Max. speed: 600 m/min
  • Control accuracy: 0.04 mm
  • Measuring accuracy: 0.001 mm
  • Number of print stations: up to 16
  • Errors: lateral and longitudinal
  • Voltage: 230 V AC
  • Frequency: 50 ~ 60 Hz
  • Presetting: optional
  • Detected register mark types: web and rectangular
  • Sensor type: fibre optics/matrix camera
  •   Key features:
  • Fibre optic/matrix camera based sensors
  • Automatic mark recognition (AMR)
  • Presetting of register compensator roller or presetting cylinders
  • Absolute encoder presetting
  • Online chart recording
  • Use of key colour or previous colour measurement mode with automatic changeover between the two
  • Possibility to measure and correct differences in print position across width (skew and shrinkage)
  • Provision to save and recall all settings of printed jobs
  • Set points can be adjusted automatically
  • Provision to generate reports on printed jobs for quality, quantity
  • Interactive icon based and multi-lingual GUI
  • Online diagnostic and service support
  • Industry 4.0 compliant software
  • Reduces start up waste
  • Quick job set up
  • Improves printing quality
  • Process optimisation improves productivity
  • Versatile and adaptable to job specific needs
  • Ease of use
  • Less hardware results in longer MTBF
